Nickel 200 Round Bar
₹ 2000-3000 per Kg
Nickel 200 Round Bar is a solid rod made from commercially pure nickel (UNS N02200). This nickel material is known for its excellent corrosion resistance, excellent toughness, and high thermal and electrical conductivity. With low electrical resistivity, it delivers reliable performance in demanding environments. It also offers strong mechanical properties, high ductility, and the ability to withstand stress without losing stability, making it suitable for shaping into custom made sizes and shapes as required.
Nickel 200 Round Bar is widely used across industries that require long-lasting and dependable nickel alloys. In the aerospace sector, it is used for engine parts, connectors, and rocket components where both strength and corrosion resistance are critical. In chemical plants, it is chosen for caustic handling equipment, heat exchangers, and storage drums because of its ability to resist alkalis and harsh chemicals. Its high electrical conductivity also makes it valuable for electronics, including battery parts, wiring, and terminals. In construction, although less common, it is used in specialized fittings, fasteners, and ornamental work where strength and durability are important. Sagar Prakash Alloys is a reputable manufacturer, supplier, stockist, and exporter of high-quality Nickel 200 Round Bar in India. They supply their products in both standard and custom-made dimensions.
Call us now for the latest Nickel 200 Round Bar price! Contact +91 22 66109388 or
email: [email protected] for a quick quote.
Nickel 200 Bar Specification
Strict quality standards are followed during the manufacturing of nickel 200 bars to ensure their reliable use in different industries. They are provided according to UNS N02200, ASTM B160 and ASME SB160 specifications ensuring durability and consistent performance.
| Specification | ASTM B160, ASME SB160 |
|---|---|
| Form | Round, Square, Hex (A/F), Bush, Rectangle, Flat, Billet, Ingot, Forging, PSQ Bar, Rod, etc. |
| Size Range | 15NB to 150NB In |
| Length | 100 mm To 3000 mm Long & Above |
| Diameter | ½" to 12" |
| Tolerance | H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold Drawn, Shot Blast & Drawn, 240 Grit Belt Polished, Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish, High Polished |
| Condition | Cold Drawn Polished, Cold Drawn Centreless Ground & Polished, Threading |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Manufacturing Process | Cold drawn / Extruded |
| Nickel 200 Flat Bar | Diameter: 3mm ~ 800mm |
| Nickel 200 Hex Bar | Size: 3mm × 20mm × 20mm ~ 12mm × 100mm × 100mm |
| Nickel 200 Square Bar | Size: 4mm × 4mm ~ 100mm × 100mm |
| Nickel 200 Rod | Thickness: 2mm ~ 100mm, Width: 10mm ~ 500mm |
ASTM B160 Nickel 200 Bar Availability
To meet the needs of different industries nickel 200 bars are manufactured in a variety of shapes. Each type is made to serve a specific function, giving easy fabrication and versatility in use.
Nickel 200 Flat Bar
Nickel 200 Hex Bar
Nickel 200 Square Bar
Nickel 200 Rod
Equivalent Grades of ASME SB160 Nickel 200 Bar
Nickel 200 Bars are available in multiple international grades for compatibility across industries. The equivalent grades include DIN, UNS, and German WERKSTOFF NR., details of which are provided in the table below.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel Alloy 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
Nickel 200 Bar & Rod Chemical Properties
The chemical composition of Nickel 200 Bar and Rod includes nickel, iron, manganese and silicon. The exact percentage of each element is listed in the table below to ensure clarity and quality assurance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel Alloy 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
Alloy 200 Bar Mechanical Properties
Alloy 200 Bars have strong mechanical properties such as tensile strength, yield strength, and elongation. These features provide durability, flexibility, and reliable performance, making Nickel Alloy Bars suitable for use in demanding applications.
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
