Aluminium Bronze Bars Supplier, Aluminium Bronze Rods , Aluminium Bronze Bar Stockist in India
Sagar Prakash Alloys is a leading Manufacturer and supplier of Aluminum Bronze Round Bars, known for their tough, strong, and highly resistant to corrosion and used in various industries. The bars possess high wear resistance, low oxidation rates at high temperatures, and do not react with sulfur compounds. Additionally, their biostatic effect helps prevent the growth of harmful organisms
Aluminium Bronze Round Bars Distributor in India, offering high-quality Round Bars in Custom Sizes.
One of the most commonly used grades, C95400 Aluminum Bronze (SAE 68), is a strong copper base alloy with 10-11.5% aluminium and 3-5% iron. It has high resistance to wear and corrosion. Having a tensile strength of 85,000 psi and hardness of 170-190 HB, the alloy excels both in industrial and marine usage. Round bar form is offered with it and is tough, machinable, and shows good high-temperature strength.
We are global exporter of high-quality C95400 Round Bars, exporting to the USA, Europe, and UAE, from India. We produce these bars with top quality material and the latest technology to match international quality standards. Our bars are of various sizes, thicknesses, and custom specifications at the lowest price per kg.
For any queries or to place your order for Aluminium Bronze Round Bars, contact us now
Aluminium C95400 Bronze Bars Specification
| Standard | ASTM B150, ASME SB150 |
| Aluminium Bronze Round Bar Size | Diameter: 3mm ~ 800mm |
| Aluminium Bronze Angle Bar Size | 3mm × 20mm × 20mm ~ 12mm × 100mm × 100mm |
| Aluminium Bronze Square Bar Size | 4mm × 4mm ~ 100mm × 100mm |
| Aluminium Bronze Flat Bar Size | Thickness: 2mm ~ 100mm Width: 10mm ~ 500mm |
| Aluminium Bronze Hex Bar Size | 2mm ~ 100mm |
| Aluminium Bronze Billet Size | 1/2″ to 495mm Diameter |
| Aluminium Bronze Rectangle Size | 33mm × 30mm to 295mm × 1066mm |
| Finish | Bright, Polish, Rough Turned, Grinding, Centreless Ground, Black |
| Length | 1000mm - 6000mm |
| Tolerance | H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled, Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawn, Polished, Centreless Ground & Polished, Annealed Round Bar |
| Technique | Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Grade | C61000, Ab1, C95600, C95400, C60800, C62300 |
ASTM B150 Aluminium Bronze Bar Availability
Aluminium Bronze Flat Bar
Aluminium Bronze Hex Bar
Aluminium Bronze Square Bar
Aluminium Bronze Rectangle Bars
Aluminium Bronze Bar Price
| Diameter (inches) | Length (inches) | Alloy Type | Price (USD) |
| 0.75 | 12 | C630 | $56.93 |
| 0.75 | 24 | C630 | $107.93 |
| 0.875 | 12 | C630 | $68.15 |
| 0.875 | 24 | C630 | $129.06 |
| 1.5 | 36 | C954 | $164.73 |
| 3.75 | 2.75 | C630 | $78.52 |
| 4.25 | 12 | C954 | $791.56 |
| 4.5 | 12 | C954 | $888.80 |
| 4.75 | 12 | C954 | $988.63 |
Note
- Prices provided are indicative and may vary based on market trends.
- Additional costs such as taxes, shipping, and customization may apply.
Aluminium Bronze Hex Bars Surface Finish
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
Aluminium Bronze Round Bars Size Chart
Aluminium Bronze Round Bar is available in standard sizes
| Bar Size | Diam. (mm) | Bar Size | Diam. (Inch) | Bar Size | Diam. (mm2) | Bar Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.625 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.625 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 |
Aluminium Bronze Hollow Bars Dimensions
| 5 | 0.2 | 0.15 | 0.25 | 0.2 | 2 | 1.57 |
| 6 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 7 | 0.38 | 0.3 | 0.49 | 0.38 | 2.8 | 2.2 |
| 8 | 0.5 | 0.39 | 0.64 | 0.5 | 3.2 | 2.51 |
| 9 | 0.64 | 0.5 | 0.81 | 0.64 | 3.6 | 2.83 |
| 10 | 0.73 | 0.63 | 1 | 0.79 | 4 | 3.14 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.4 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 18 | 2.54 | 2 | 3.24 | 2.54 | 7.2 | 5.65 |
| 20 | 3.14 | 2.47 | 4 | 3.14 | 8 | 6.28 |
| 22 | 3.8 | 2.98 | 4.84 | 3.8 | 8.8 | 6.91 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.8 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16 | 12.57 | 16 | 12.57 |
| 45 | 15.9 | 12.49 | 20.25 | 15.9 | 18 | 14.14 |
| 50 | 19.62 | 15.41 | 25 | 19.64 | 20 | 15.71 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64 | 50.27 | 32 | 25.13 |
ASTM B150 Aluminium Bronze Bars Chemical Composition
| Cu | Sn | Zn | Ni | Al | Fe | Mn | Pb |
| 79% min | 0.10% max | 0.50% max | 4.00 – 5.00% | 8.50 – 9.50% | 3.50 – 4.50% | 0.80 – 1.50% | 0.05% max |
Aluminium Bronze Bars Mechanical Properties
| Tensile Strength MPa | 0.2% Proof Stress MPa | Elongation % | Hardness HB |
| 590 – 655 | 240 – 260 | 18 – 25 | 150 – 170 |
Aluminium Bronze Bars Equivalent Grades
| UNS | SAE | AS 1565 | BS1400 | DIN | AS | BS | ASTM | USA |
| C95800 | CA958 | C95810 | AB2 | CuAl10Ni | 1565-1998- C95210/C95810 | 1490 AB2 | ASTM 952/SAE 68A/68B | C95500 |
Aluminum Bronze Rod Bar Physical Properties
| Density (G/Cm³) | 8.89 |
| Density (Lb/In³) | 0.321 |
| Melting Point (°C) | 1435 – 1446 |
| Melting Point (°F) | 2615 – 2635 |
